Product Detail

Car folded monitoring lifting equipment


Code : GL-196
Price : Power Conference
Material : Al-Mg alloy
Quantity : 10000000
Brand : GALLO
Type : Vehicle monitoring
Detail



Wuxi Gallo Technology Co., Ltd. is specialized in automotive head technology, vehicle monitoring folding lifting equipment, mobile lighting technology, research and development and product manufacturing lifting mast of enterprises have passed ISO9001: 2000 international quality system certification.

     Wuxi Gallo folding monitoring technology production car lifting equipment with small size, light weight, load, safety, illumination light, shock resistance is small, self-loading buffer strong, stable performance, etc., technology has reached world advanced level. Car folded monitoring lifting equipment using high-strength aluminum alloy, light weight, complete specifications, and design and production according to the needs of users, in order to meet the needs of different occasions in different areas of the height and load. In a variety of natural disasters, emergencies and rescue at night scene, plays an important role in the rescue.

     Folding Car lifting equipment monitoring device is lifting mast lighting professional mobile monitoring equipment provided. It will lift mast mounted on top of the device or peripheral, will rise to a height vertically to achieve the intended function of lifting equipment customers such as lighting equipment, camera equipment, antennas and equipment move.

车载折叠照明升降设备

(Figure: Car folded monitoring lifting equipment)



(A) monitoring the folding car lifting equipment technical indicators

     1 Collection Height: customized according to customer requirements

     2 total rise height: customized according to customer requirements

     3 Installation: customized according to customer requirements

     4.Material: Car folded monitoring lifting equipment using high-strength aluminum-magnesium alloy extrusions, strong corrosion resistance; cylinder walls using high-pressure treatment process seal wear and porcelain join.

     5 packing properties: a high level of sealing performance, the stationary state 24 hours lifting mast fell less than 10mm. Vehicle lifting equipment used to monitor folding swinging piston stroke gassing structure which a piston re-containing high-strength graphite PTFE; transmission are all closed, the rubber sealing ring for sealing between the rod and the rod body (this ring is imported from Japan seals NOK), waterproof sand performance, strong corrosion resistance;

     6 Surface treatment: hard anodized aluminum-magnesium alloy increases the intensity profiles;

     7 wind resistance: Car lifting equipment monitoring folding lever body with circular cross-section, in the same installation space, circular cross-section can provide higher strength, stiffness, torsional and bending ability ability; wind 8; with anti-rotation function, working pressure:. <0.30 Mpa ;.

     8 Car folded structure monitoring device has a built-lift lines; my company first realized the device control and power cables inside the lift rod fixed at the earliest to achieve the lift rod internal traces on the appearance and performance of more further.

     9 Car lifting equipment is monitored by folding the roof fixed, or installed in vehicles surrounding and supporting frames by dragging the disc and joint fixation. Customer equipment selection, car lift mast should be determined according to the different type of the original height of the top of the mounting surface height. When mounted on top of the resulting product, the original height of the shortest, to ensure that the body has a maximum height as far as possible by reducing the resistance and drag of the device.

   (B) monitor the lift car folding device performance advantages

    Car folded monitoring lifting equipment are made from high quality aluminum alloy material, the entire manufacturing process through extrusion, drawing, honing, machining, anodizing and other multi-channel technology, and undergo a rigorous inspection process to ensure that the car folding quality monitoring lifting equipment. Folding Car lifting equipment monitoring advantages are: simple structure, sophisticated manufacturing process, and therefore easy to use, stable performance. Specifications Car folded monitoring lifting equipment is in accordance with the number of different sections, the biggest festival diameter, initial height, maximum height and determined. Different specifications of the car lifting equipment monitoring different folding its technical performance.


车载折叠照明升降设备

(Folding Car lifting equipment monitoring application example a)



(C) monitor the lift car using the techniques described folding equipment

    Self-locking latch is based on the structural characteristics of the model car folding cylinder monitoring mast lifting equipment, shear force of the cylinder wall section of the full-length sleeves and a foreign key between the spring pin on the lift mast sections for mechanical positioning . Its effect depends on the location and the cross-sectional area of the key material. Since the lifting mast lift cylinder vehicle monitoring device folded material is aluminum alloy, cross-sectional area bonds is small, so that the latch lock device is only applicable to small and medium sized car lighter load lifting equipment folding monitor.

Straight pull self-locking generally applicable to the initial height of 1.6m below the mast, cable-stayed self-locking applies to the initial height of 1.6m above the mast.

Brake lock braking effect is realized by holding the friction between the brake lever and lift, the equivalent of wheels and brakes. When using the self-locking brake mast requires spin hug gates. Braking force required size, depending on the size of the decision of loads, the more tight spin braking force greater. The actual operation, the use of a torque wrench, you can clear whether the braking force to meet the load requirements. Wrench or torque wrench is optional, self-locking brake braking force is calculated by using the formula screw tightening torque.

For tightening torque value, Nm

Screw receiving optimum clamping force F, N;

d thread diameter, mm; [1] P is the thread pitch, mm

Integrated brake and separate brake brake can achieve the same effect, the difference is that the design can meet the initial height of the mast, the greatest increase, requiring load. Under the same conditions, the separation of the initial brake-in holding the lower mast height can be made higher or liters.

   We provide professional services include:

    1, pre-service

    We accept folding car lifting equipment monitoring product customization and OEM production needs. Even with a standard product, due to different customers different requirements, some indicators are not the same concern. As long as you make on-board folding lifting equipment monitoring parameters required from the total height, shut height, wind resistance, vertical load, partial load, lifting time,, yaw to the power requirements of form, weight, installation methods, we are responsible for you customize a part of your special car folding monitoring lifting equipment.

    2, service

    Our company can arrange for clients and friends of professional and technical personnel to guide the installation. Warranty: One year replacement, a three-year warranty and lifetime maintenance (within 48 hours to reach the scene).

    Car folded monitoring lifting equipment and more product information, please pay attention to and collection of Wuxi site Gallo technologyhttp://www.wxgallo.com/

车载折叠照明升降设备

(Folding Car lifting equipment monitoring application example two)
